3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment

3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment
3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment

Gambar besar :  3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment

Detail produk:
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1
Harga: 13608
Kontak
Detil Deskripsi produk
Model no.: Daf Kapasitas: 5m3/jam
Kompresor Udara: 0,55kw Daya Pompa Terlarut: 3kw
Kekuatan Skimmer: 0.1kw Kekuatan Agitator Koagulasi: 0,55kw
Kekuatan Agitator Flokulasi: 0,55kw Kekuatan Pengaduk pH: 0,55kw
Ukuran: 3600*1700*1850mm Kapasitas produksi: 100000/minggu
Konten SS: ppm atau mg/L Kandungan minyak: ppm atau mg/L
Rentang pH: 6 ~ 9 Konten Direksi: ppm atau mg/L
Konten COD: ppm atau mg/L
Menyoroti:

3600*1700*1850mm Specification DAF System

,

0.1kw Skimmer DAF System

,

0.55kw Coagulate Agitator DAF System

Dissolved Air Flotation (DAF) Machine for Paper Making Industrial Wastewater Treatment
DAF System Introduction
The Dissolved Air Flotation system is a water treatment process that clarifies wastewaters by removing suspended matter such as oil or solids. This is achieved by dissolving air in the water under pressure and then releasing it at atmospheric pressure in a flotation tank. The released air forms microbubbles that adhere to suspended particles, causing them to float to the surface where they can be removed by a skimming device.
DAF System Work Process
  1. Wastewater enters coagulation (RT1) and flocculation (RT2) reaction tanks from the equalization tank
  2. Water coagulates with PAC and flocculates with PAM to form flocs
  3. Wastewater and dissolved water enter the DAF tank reaction zone
  4. Microbubbles and flocs combine to form low-density particles that float to the surface
  5. Scum is scraped to the slag tank while clean water collects below
  6. Most water is discharged while a portion recirculates to form dissolved water
3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 0
DAF System Fabrication Process
3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 1
Technical Data
3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 2
DAF System Features
  • Microbubble generation technology
  • Subsurface capture mechanism
  • Automatic slagging controlled by liquid level
  • Non-clogging release with high efficiency
Applications
  • Municipal sewage treatment
  • Slaughter house wastewater
  • Metallurgical industry wastewater
  • Spraying sewage
  • Printing & dyeing sewage
  • Metal-processing sewage
  • Mining stone wastewater
  • Electronic sewage treatment
Model Selection Criteria
To select the appropriate DAF system model, consider these factors:
  • Wastewater type (dairy, car washing, slaughter house, food processing, etc.)
  • Suspended solids content (ppm or mg/L)
  • Oil, grease, fat, and FOG content (ppm or mg/L)
  • pH level (6-9 preferred; corrosive substances may require special materials)
  • BOD and COD levels (ppm or mg/L)
3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 3
Packaging Information
3600*1700*1850mm Specification DAF System with 0.1kw Skimmer and 0.55kw Coagulate Agitator for Industrial Wastewater Treatment 4

Label:

Unit DAF pengolahan air limbah,

Pengolahan air limbah DAF,

Pabrik pengolahan air DAF
